PSA-2150

PROFESSIONAL  ANALOG STEREO AMPLIFIER

1) 75Wx2/100Wx2/150Wx2 (RMS, 8ohm)

Specification:

*With MCU control, with LCD display
*Dual Binding Post Speaker Output
*Two Way Crossover & High Out Jacks
*Crossover switch (150Hz X over)
*Thru/Low Out jacks  & Low cut switch
*Three Speakon Connectors (CH A/CH B/Bridge)
*Sub- Sonic (Low Cut) Filter
*Two-Speed Fan
*2 Ohm Load Per Channel
*4 Ohm In Bridge Mode
*Combo Inputs Connector XLR & 1/4'' Phone Jack.
*Thru/Low Out And High Out 1/4'' Jacks
*2x5 Led Input Level Indicator
*Overload And Protection Indicator
*Signal/Noise Ratio:=102db  & Distortion:=1.0%
*Frequency Response:20hz-20khz Less Than±0.5db
*Input Impedance: Balance 20ko & Input Level:+4db
*Amplifier Protection: Full short circuit, thermal and HF protection, stable into reactive or mismatched loads
*Power supply: 100-120V, 50/60HZ 15A   &  220-230V, 50/60HZ 8A
*Meas: 88Hx482Wx400D(mm)
