•Totally 8-CH Audio Mixing System with 6 Mono MIC Input & 2 Stereo Inputs
•Professional Power Mixer Wood Box Amplifier
•SMT(Surface Mounting Technology) for Reliable performance
•Bluetooth Wireless Music Streaming Works with Virtually Any Bluetooth Enabled Device
•With USB MP3 Player w/LED Display w/ Recorder Digital Effects
•24 Programs of Digital DSP Effects w/LED Display and Parameterof Each Program Adjustable
•Master Dual 7-Band Graphic Equalizer w/ Output Level LED Indicators
•All XLR Microphones Inputs with +48V Phantom Power Supply
•8 3-Pin Low Impedance XLR Balanced Microphone Inputs
•8 1/4'' TRS High Impedance Un-balanced Inputs
•Independent MIC Level / MIC DSP Effect Send Level Control
•Independent MIC Treble/Mid/Bass/Gain Level Control
•Independent MIC PEAK LED Indicators
•PAD Function to Make Each MIC Input Attenuate 20dB
•Effect Send/Effect Return/ Effect Level Adjustable
•Additional RCA Inputs: RCA Tape Input (L/R), RCA Tape Output (L/R),TRS Effect Send/Effect
Return (L/R), & TRS Main Out (L/R)
•Headphone Output: 1/4'' TRS Stereo Connector
•MP3 & Tape In with HI/LOW/ Level Control
•Main Output Level L & R Control
•The power voltage depends on the request of customers.

Technical Specs:

•Line Level Impedance 10K Ohms @ -10dBv
•Mono Microphone Inputs (MIC Pre-Amp)
•XLR: Electronically Balanced Discrete Input Circuit
•Frequency Response: <10Hz–150kHz (-1dB), <10Hz–200kHz (-3dB)
•Gain Range: +10 - +60dB
•Max. Input Level: +12dBu @ +10dB Gain
•Impedance: Approx. 2.6k Ω Balanced
•Signal-to-Noise Ratio: 110dB / 112dBA – Weighted
•Distortion: (THD+N): 0.1% / 0.05% A- Weighted
•Channel Equalization: Control Range
•High @ 10KHz +/-15dB, Mid @ 2.5KHz +/-15 dB, Low  @ 80Hz +/-15dB
•Master EQ Frequency Hz: 63Hz, 125Hz, 400Hz, 1KHz, 2.5KHz, 6.4KHz, 15KHz
•Effects Loop & Send: 1/4” TRS Connectors Unbalanced
•Impedance: Approx. 1k Ohm -10dBv
