8-CH BT AUDIO POWERED MIXER WITH MIC & LINE INPUTS, MP3 PLAYER, 24 PROGRAMS OF DIGITAL DSP EFFECT & 48V PHANTOM POWER SUPPLY

Features:

• Totally 8-CH Audio Mixing System with 6 Mono MIC Input & 2 Stereo Inputs
• Professional Power Mixer Wood Box Amplifier
• SMT(Surface Mounting Technology) for Reliable performance
• Bluetooth Wireless Music Streaming Works with Virtually Any Bluetooth Enabled Device
• With USB MP3 Player w/LED Display w/ Recorder Digital Effects
• 24 Programs of Digital DSP Effects w/ LED Display and Parameter of Each Program
 Adjustable
• Master Dual 7-Band Graphic Equalizer w/ Output Level LED Indicators
• All XLR Microphones Inputs with +48V Phantom Power Supply
• 6/8/10 3-Pin Low Impedance XLR Balanced Microphone Inputs
• 6/8/10 1/4'' TRS High Impedance Un-balanced Inputs
• Independent MIC Level / MIC DSP Effect Send Level Control
• Independent MIC Treble/Mid/Bass/Gain Level Control
• Independent MIC PEAK LED Indicators
• PAD Function to Make Each MIC Input Attenuate 20dB
• Effect Send/Effect Return/ Effect Level Adjustable
• Additional RCA Inputs: RCA Tape Input (L/R), RCA Tape Output (L/R),  TRS Effect
 Send/Effect Return (L/R), & TRS Main Out (L/R)
• Headphone Output: 1/4'' TRS Stereo Connector
• MP3 & Tape In with HI/LOW/ Level Control
• Main Output Level L & R Control
• The power voltage depends on the request of customers.

Technical Specs:

• Power Optional:2CHx200W,4ohm,RMS
 • 8/4 Ohm Impedance Each Channel
• Line Level Impedance 10K Ohms @ -10dBv
• Mono Microphone Inputs (MIC Pre-Amp)
• XLR: Electronically Balanced Discrete Input Circuit
• Frequency Response: <10Hz–150kHz (-1dB),  <10Hz–200kHz (-3dB)
• Gain Range: +10 - +60dB
• Max. Input Level: +12dBu @ +10dB Gain
• Impedance: Approx. 2.6k Ω Balanced
• Signal-to-Noise Ratio: 110dB / 112dBA – Weighted
• Distortion: (THD+N): 0.1% / 0.05% A- Weighted
• Channel Equalization: Control Range
• High @ 10KHz +/-15dB, Mid @ 2.5KHz +/-15 dB, Low @ 80Hz +/-15dB
• Master EQ Frequency Hz: 63Hz, 125Hz, 400Hz, 1KHz, 2.5KHz, 6.4KHz, 15KHz
• Effects Loop & Send: 1/4” TRS Connectors Unbalanced
• Impedance: Approx. 1k Ohm -10dBv
